DS200 Digital Precinct Scanner | EVS 6.0.2.1 | Poll Worker Guide v 1.1.CBB Page | 7
Preparing the DS200 for Use
DS200 Scanner Setup
The DS200 Scanner and Ballot Box use two
different keys: a standard silver key and a barrel
key.
The silver ballot box key is used only for the
ballot box locks. The barrel key is used only for
locks on the DS200 scanner. You will need both
keys to open and start the DS200.
Open the front of the carrying case by using the
silver ballot box key and unlatching the two front
tabs.
Powering Up the Scanner
Using the barrel key, open the DS200 touch
screen.
If the machine is plugged in, the scanner should
automatically power on when the screen is lifted.
If the scanner does not automatically power
on, use the barrel key to open the Front Access
Compartment and press the Power button.
Preparing the Printer Tape
The DS200 contains an internal thermal printer
for reports. To change a tape roll, open the Front
Access Compartment and press the blue lever.
Replace the tape roll and pull the end of the
paper out of the tape opening with the treated
side facing the right side of the opening.

DS200数字选区扫描仪| EVS 6.0.2.1 |投票工人指南V1.1。CBB第7页
准备使用DS200
DS200扫描仪设置
DS200扫描仪和投票箱使用两个
不同的钥匙：一把标准的银钥匙和一把桶
钥匙
银色投票箱钥匙仅用于
投票箱的锁。桶形钥匙仅用于
锁定DS200扫描仪。两者都需要
打开和启动DS200的按键。
打开手提箱的前部，方法是使用
银制投票箱钥匙和打开前两个门闩
标签。
给扫描仪通电
使用桶形键，打开DS200触摸屏
屏幕
如果机器已插入电源，扫描仪应
屏幕升起时自动通电。
如果扫描仪没有自动通电
在上，使用桶形钥匙打开前部通道
然后按下电源按钮。
准备打印机磁带
DS200包含一个内置热敏打印机
用于报告。要更换胶带卷，请打开正面
进入储物箱并按下蓝色操纵杆。
更换胶带卷并拉动胶带的末端
用经过处理的纸张从胶带开口中取出
面向开口右侧的一侧。
