3-2. Create the Configuration File
11/98 3-5 U3-1050
Westinghouse Proprietary Class 2C
3-2.1. Analysis of the Sample File
The example in Figure 3-1 is for a Modbus link operating at a baud rate of 19200
with even parity. LC memory location 2000 will receive the link software’s status
information.
Group one will be executed periodically at an interval of five seconds. Using the
Modbus command Force Multiple Coils, digital states found in LC memory at
addresses 0000 through 0011 will be sent to Modbus slave 1 coils C1249 through
C1260.
Group two will be executed periodically and, because the interval has not been
specified, it defaults to zero and the group is executed as often as possible. A
message using Modbus function Preset Multiple Registers will be sent to Modbus
slave 2 to transfer the IEEE format floating point values at LC memory addresses

3-2. 创建配置文件
1998年11月3-5日U3-1050
西屋专有2C级
3-2.1. 示例文件的分析
图3-1中的示例适用于波特率为19200的Modbus链路
平分。LC内存位置2000将接收链路软件的状态
信息
一组将以五秒钟的间隔定期执行。使用
Modbus命令强制多个线圈，在
地址0000至0011将通过发送至Modbus从机1线圈C1249
C1260。
二组将定期执行，因为时间间隔尚未确定
如果指定，则默认为零，并尽可能频繁地执行组。A.
使用Modbus功能预设的消息多个寄存器将被发送到Modbus
从机2在LC内存地址传输IEEE格式浮点值
