3500个模块，

不包括120M8155-01

l 3500型（机架本身和任何附带的显示器）必须安装在适当的外壳内，外壳的防护等级至少为IP54，并符合相关要求

EN 60079-0的外壳要求。

l对于带有内部安全栅的装置：因为安全栅电路参考接地，所以它们参考接地

不符合EN 60079-15:2010中规定的介电强度要求。这应该是

在终安装时考虑。

l对于内部屏障：按照控制图纸138547进行安装。

l应提供瞬态保护，其设置水平不超过峰值的140%

设备电源端子的额定电压值。

l设备只能在污染程度不超过2级的区域使用，如下所示：

定义见IEC 60664-1。

120M8155-01 l根据IEC 60079-0，终显示器安装必须符合IP54额定外壳。

3500 Modules,
excluding 120M8155-01
l The Model 3500 (both the rack itself and any included displays) must be housed in a suitable enclosure that provides a degree of protection of at least IP54 and meets the relevant
enclosure requirements of EN 60079-0.
l For units with internal barriers: Because the barrier circuits are referenced to earth, they do
not meet the dielectric strength requirement specified in EN 60079-15: 2010. This shall be
considered during final installation.
l For  internal barriers: Installation is to be in accordance with control drawing 138547.
l Transient protection shall be provided that is set at a level not exceeding 140% of the peak
rated voltage value at the supply terminals to equipment.
l The equipment shall only be used in an area of not more than pollution degree 2, as
defined in IEC 60664-1.
120M8155-01 l The final display installation must meet IP54 rated enclosure per IEC 60079-0.
