VDIPF0752
参数
名称功能范围/选项
Pswrd配置参数菜单访问密码范围为：0到1000
%RH disp（相对湿度显示）允许在低于室温的情况下打开或关闭%RH
DI1定义二进制输入DI1 None、Rem NSB、RemOVR、Filter、Service、Fan lock的使用
锁定设置键盘锁定级别0、1、2
Pwr del将恒温器的通电延迟设置为10至120秒
Frost pr启用或禁用防冻保护
Heat max将大加热设定点限制设置为40至90°F（4.5至32.0°C）
Cool min将小冷却设定点限制设定为54至100°F（12.0至37.5°C）
反周期设置阶段0、1、2、3、4、5的小开/关操作时间
加热cph设置每小时加热阶段的大循环次数3、4、5、6、7、8
冷却cph设置每小时冷却阶段的大循环次数3、4、5、6、7、8
死区设置冷却和加热设定点2、3或4°F（1.0至2.0°C）之间的小死区
风扇控制将风扇控制模式设置为打开或关闭
Fan del在需求结束打开或关闭后将风扇运行时间延长60秒
Com Addr*将恒温器的Com地址0设置为254
盘ID**将节温器的盘ID设置为0至500
通道**将节温器通道10设置为26
Get From**选择恒温器将配置从0导入254
TocTime设置覆盖时的临时占用时间。0到12小时（以1小时为增量）
校准RS室温传感器校准±5.0°F
Cal OS外部空气温度传感器校准±5.0°F
H阶段设置使用的加热阶段数1或2
C阶段设置使用的冷却阶段数1或2
H锁设置外部空气温度加热锁定-15至120°F（-26至49°C）
C锁定设置外部空气温度机械冷却锁定-40至95°F（-40至35°C）
Unocc TM将未占用计时器值设置为0.0到24小时（以0.5小时为增量）
2/4event设置占用计划2或4的事件数
aux cont将辅助触点设置为常开或常闭常开或常闭
Prog rec启用或关闭渐进式恢复功能
RH设定值重置的RH LT低外部温度-40至15°F（-40至9.5°C）
RH设定值重置的RH HT大外部温度-20至55°F（-6.5至13°C）
HL Sp上限电源湿度设定值50至90%
Dhu OALK禁用除湿的外部空气温度-40至122°F（-40至50°C）
Dhu LCK启用或禁用duhum的锁定功能。输出开或关
DehuHyst将除湿滞后值设置为2到20%
根据RH LT 10至90%重置RH设定点的RE Sp值
RH cal相对湿度传感器校准±15%
显示HL显示上限传感器值显示上限传感器值

Parameter name Function Range/Options Pswrd Configuration parameters menu access password Range is: 0 to 1000 %RH disp Enables %RH to be displayed below room temperature ON or OFF DI1 Defines the use of binary input DI1 None, Rem NSB, RemOVR, Filter, Service, Fan lock Lockout Sets the keypad lockout level 0, 1, 2 Pwr del Sets the power-up delay of the thermostat 10 to 120 seconds Frost pr Enables frost protection ON or OFF Heat max Sets the maximum heating setpoint limit 40 to 90 °F ( 4.5 to 32.0 °C ) Cool min Sets the minimum cooling setpoint limit 54 to 100 °F ( 12.0 to 37.5 °C ) Anticycle Sets minimum On/Off operation time for stages 0, 1, 2, 3, 4, 5 Heat cph Sets the maximum number of cycles for heating stages per hour 3, 4, 5, 6, 7, 8 Cool cph Sets the maximum number of cycles for cooling stages per hour 3, 4, 5, 6, 7, 8 Deadband Sets the minimum deadband between cooling & heating setpoints 2, 3, or 4 °F ( 1.0 to 2.0 °C ) Fan cont Sets the fan control mode ON or OFF Fan del Extends fan operation by 60 seconds after demand ends ON or OFF Com Addr* Sets the Com address of the thermostat 0 to 254 PAN ID** Sets the PAN ID of the thermostat 0 to 500 Channel** Sets the channel of the thermostat 10 to 26 Get From** Chooses thermostat to import configuration from 0 to 254 TOccTime Sets the temporary occupancy time when overriding. 0 to 12 hours (in 1 hour increments) Cal RS Room air temperature sensor calibration ± 5.0 °F Cal OS Outside air temperature sensor calibration ± 5.0 °F H stage Sets the number of heating stages used 1 or 2 C stage Sets the number of cooling stages used 1 or 2 H lock Sets the outside air temperature heating lockout -15 to 120 °F ( -26 to 49 °C ) C lock Sets the outside air temperature mechanical cooling lockout -40 to 95 °F ( -40 to 35 °C ) Unocc TM Sets the unoccupied Timer value 0.0 to 24 hours (in 0.5hr increments) 2/4event Sets the number of events for the occupancy schedule 2 or 4 aux cont Sets the auxiliary contact to N.O. or N.C N.O. or N.C Prog rec Enables the progressive recovery function ON or OFF RH LT Minimum outside temperature for RH setpoint reset -40 to 15 °F ( -40 to 9.5 °C ) RH HT Maximum outside temperature for RH setpoint reset -20 to 55 °F ( -6.5 to 13 °C ) HL Sp High limit supply humidity setpoint 50 to 90% Dhu OALK Outside air temperature under which dehumidification is disabled -40 to 122 °F ( -40 to 50 °C ) Dhu LCK Enables or disables the lockout functions for the duhum. output ON or OFF DehuHyst Sets the value for the dehumidification hysterisys 2 to 20% RE Sp Value at which the RH setpoint will be reset based on RH LT 10 to 90% RH cal Relative humidity sensor calibration ± 15% Display HL Displays the high limit sensor value Displays the high limit sensor value
