•恢复油位，并以相同方式组装下一个散热器。
3.4.7编组箱
•编组箱应安装到位。O.T.I.和W.T.I.袋中应装满变压器油。
O.T.I.和W.T.I.灯泡应安装在各自的口袋中。
•将O.T.I.和W.T.I.的“报警”和“提示”触点设置为所需值。O、 T.I，设置A=85°C&T=95°C
W、 T.I.，A=95°C和T=105°C的设置被视为良好。可以根据当地情况制定
条件
3.4.8电缆箱
•当提供电缆盒时，应安装电缆盒并进行电缆端接。充油电缆盒应适当充油。在“母线槽”连接的情况下，变压器配有法兰
接收母线槽。由于连接和安装应通过端子连接至架空线路
连接器。
3.5空气释放
•通过缓慢拧下衬套、衬套袋、瓦斯炉处的放气塞来释放空气
继电器、主油箱盖、油电涌继电器等，来自11、22 8t 33 KV的纯瓷套管，空气可
松开螺母，压下橡胶垫片，然后向下压下金属零件，即可释放。
3.6油取样和过滤
•不得直接从油桶或运输容器向变压器中注油，因为有可能
沉淀水或沉淀物也可能与油一起泵入变压器。
•桶或运输容器中的油应填充到储油罐中，油参数应
在注入变压器之前进行测试。
•如果油桶中收到油，应从尽可能多的油桶中取样进行测试。
表-1
从桶中选择样品
批次中的桶数从中取样的桶数
2至5 2
6至20 3
21至50 4
61至100 7
101至200 10
201至400 15
401及以上20
TBI AF/IMS001/R3变压器安装、调试、运行和维护
44 | P a g e
•应从滚筒底部采集样本进行测试。
•如果容器中收到油，应通过油箱出口的取样阀收集油样，或
根据建议，使用盗斗从桶中取样。应允许容器
在抽取样品之前，至少静置一小时。
•进行以下测试，以确定油的质量。
 击穿电压试验
 含水量试验
 棕褐色三角洲
 电阻率
•如果油不符合规定的标准，则应在加油前过滤油并储存在储油罐中
进入变压器。从桶中泵油时，桶可能会适当倾斜，以确保
从每个桶中取出完整的油。
3.7保持质量的预防措施
•作为限制水分吸收的预防措施，变压器不应
在大气中连续暴露8小时以上，应安排安装工作
照着
•对于400 kV及以上的高压作业，应净化露点低于-400℃的干燥空气
内部装配工作期间，在油箱内部。
