5X00332G01
EIOC硬件规范：对于单工，每个系统的EIOC以太网输入/输出卡号为60输入功率+24 VDC±10%，大325 mA；冗余散热（冗余）大575 mA，单工大7 W；冗余保险丝保护（内部）的大功率为13瓦内部不可更换保险丝安装在双水平载波通信上的一个或两个插槽冗余以太网连接通过双水平载波连接到：a）以太网设备网络b）区域控制网络（ACN）ACN网络寻址在调试期间自动分配设备网络寻址手册，仅客户端控制模块限制2000个大数据值发送4000个/秒大数据值接收500个/秒大输入/输出网络节点300*模块执行速度100ms、200ms、500ms、1s、2s、5s、10s、30s、60s LED指示灯绿色–电源指示直流电源已应用红色–错误指示错误状态绿色–活动/备用指示每个EIOC的工作模式黄色闪烁–Pri/第。CN表示有效的控制网络通信

EIOC Hardware Specifications Specifications for the Ethernet I/O Card Number of EIOCs Per System 60 Input Power +24 VDC ± 10% at 325 mA maximum for simplex; 575 mA maximum for redundant Heat Dissipation (Redundant) 7 Watts maximum for simplex; 13 Watts maximum for redundant Fuse Protection (Internal) Internal Non-replaceable Fuse Mounting One or two slots on the Dual Horizontal Carrier Communication Redundant Ethernet connections via Dual Horizontal Carrier to the: a) Ethernet Device Network b) Area Control Network (ACN) ACN Network Addressing Auto Assigned during commissioning Device Network Addressing Manual, Client only Control Module Limit 2000 Max Data Values Sent 4000/second Max Data Values Received 500/second Max I/O Network Nodes 300* Module Execution Rates 100ms, 200ms, 500ms, 1s, 2s, 5s, 10s, 30s, 60s LED Indicators Green – Power Indicates DC power is applied Red – Error Indicates an error condition Green – Active/Standby Indicates operating mode of each EIOC Yellow flashing – Pri./Sec. CN Indicates valid control network communication
