连接电源线。
图 3. SCXI 机箱配置
PXI/SCXI 组合机箱
机箱的 PXI 端必须安装系统控制器。如要订购已配置的 PXI/SCXI 组合机箱，请访问
ni.com/info 并输入 rdfis5 查询。
1. 关闭 PXI 和 SCXI 电源开关，断开机箱电源。
2. 将 SCXI 机箱地址开关设置为合适的位置。图 4 中，所有开关都处于 OFF 位置。
3. 在电压选择器中设置适当的电压。详细信息见机箱的说明文档。
4. 连接电源线。
1 前端
2 后端
3 机箱电源开关
4 机箱地址开关
5 电压选择器
6 电源线连接器
ADDRESS
ON
5
4
3
2
1
SCXI
120Va~c
5
4
3
2
1
POWER
RESET


ADDRESS
1 2
4
5
6
3
SCXI
Connect the power cord.
Figure 3 Scxi chassis configuration
PXI / scxi combined chassis
The PXI end of the chassis must be equipped with a system controller. To order a configured PXI / scxi combo chassis, visit
ni. COM / info and enter rdfis5 to query.
1. Turn off the PXI and scxi power switches and disconnect the chassis power.
2. Set the scxi chassis address switch to the appropriate position. In Figure 4, all switches are in the off position.
3. Set the appropriate voltage in the voltage selector. See the description document of the chassis for details.
4. Connect the power cord.
1 front end
2 back end
3 chassis power switch
4 chassis address switch
5 voltage selector
6 power cord connector
ADDRESS
ON
five
four
three
two
one
SCXI
120Va~c
five
four
three
two
one
POWER
RESET
ADDRESS
1 2
four
five
six
three
SCXI
