Response
address function register address no. of registers crc-16
first register
crc-16
11/98 B-1 U0-1135
Westinghouse Proprietary Class 2C
Appendix B. Modbus Interface Control
Extensions
B-1. Section Overview
Several point group attributes and commands have been added to the Modbus
interface to provide more functionality than a straightforward mapping of LC
module data and Modbus slave data.
B-2. Point Group Attribute Extensions
Two new point group attributes have been added:
• Triggered Operation (Section B-2.1)
• Non-sorted Operation (Section B-2.2)
B-2.1. Triggered Operation
When the group operation Trigger is chosen and a trigger address is specified, the
entire point group is executed only when the trigger point changes.
The trigger point may be of any type. If the trigger is a digital or a bit of a packed
group point, the point group will be executed when the state changes from reset to
set..

回答
地址功能寄存器地址寄存器编号crc-16
登记
crc-16
1998年11月B-1 U0-1135
西屋专有2C级
附录B.Modbus接口控制
扩展
B-1。章节概述
Modbus中添加了多个点编组属性和命令
接口提供了比简单的LC映射更多的功能
模块数据和Modbus从属数据。
B-2。点编组属性扩展
添加了两个新的点编组属性：
•触发操作（第B-2.1节）
•非分拣操作（第B-2.2节）
B-2.1。触发操作
选择组操作触发器并指定触发器地址时
整个点编组仅在触发点更改时执行。
触发点可以是任何类型。如果触发器是数字的或有点压缩的
组点，当状态从重置更改为
设置
