Group two of the example specifies the signals to be sent to the controller. An
analysis of the first line shows the signal “unit 1 run” will be had from LC module
register 40 using SLCDOUT. The Modbus function Force Multiple Coils will be
used to send the data to Modbus unit 5. The data will be sent “by exception”
meaning the message is formed and sent only when the state of one of the specified
locations changes. The state will be sent to coil C10001 (represented by 0000 in the
protocol as explained in Section 3).
7-2. Examples
U3-1050 7-4 11/98
Westinghouse Proprietary Class 2C
7-2.2. Example 2
This example illustrates reading sixteen bit Modbus registers into all four LC
address name types (see Section 3). A mix of Modbus holding registers and input
registers is used. Remember that the character “#” introduces a comment.
/FILE: title= "Example 2",
platform= RLC
baud= 9600
/GROUP: name = "all types",
number = 1,
operation = PERIODIC
D0100, RHR, 1, 0000.00 # HR40001 bit 0 into LC reg 100

示例的二组指定要发送给控制器的信号。一
对一行的分析表明，LC模块将发出信号“一单元运行”
使用SLCDOUT注册40。Modbus功能强制多个线圈
用于将数据发送至Modbus五单元。数据将“例外”发送
这意味着只有当其中一个指定的
地点改变了。该状态将被发送至线圈C10001（在
协议如3节所述）。
7-2. 例子
U3-1050 7-4 11/98
西屋专有2C级
7-2.2. 例2
本示例说明了如何将16位Modbus寄存器读入所有四个LC
地址名称类型（见3节）。Modbus存储寄存器和输入的混合
使用寄存器。记住，字符“#”引入了注释。
/文件：title=“示例2”，
平台=RLC
波特=9600
/GROUP:name=“所有类型”，
数字=1，
操作=周期性
D0100，RHR，10000.00#HR40001 LC reg 100的0位
