operation = PERIODIC
D0040, FMC_E, 5, 0000 # unit 1 run
D0041, FMC_E, 5, 0001 # unit 2 run
D0042, FMC_E, 5, 0002 # unit 3 run
Figure 7-1. Configuration File Example 1
7-2. Examples
11/98 7-3 U3-1050
Westinghouse Proprietary Class 2C
The next six lines read in the digitals. A field by field analysis of the first of these
shows the Unit 1 running signal will be placed in LC module register 30 in a format
suitable for use with algorithm SLCDIN. The Modbus function Read Holding
Registers will be used to retrieve the signal from Modbus unit 5. The holding
register to be read is HR40010 (represented by 0009 in the protocol as explained in
Section 3). The zeroth bit of the register is used. The next five lines use bits 1
through 5.

操作=周期性
D0040，FMC\U E，5，0000#一单元运行
D0041，FMC\U E，5，0001#二单元运行
D0042，FMC\U E，50002#三单元运行
图7-1。配置文件示例1
7-2. 例子
1998年11月7-3 U3-1050
西屋专有2C级
接下来的六行是数字。对其中一个进行逐场分析
显示一单元运行信号将以以下格式放置在LC模块寄存器30中
适用于算法SLCDIN。Modbus功能读取保持
寄存器将用于从Modbus五单元检索信号。货舱
要读取的寄存器是HR40010（协议中用0009表示，如中所述）
3节）。使用寄存器的0位。接下来的五行使用位1
到5。
