Table 6-1. Modem Status Word (ModemStatusReg)
Bit Status Description
0 ATTACHED Reflects state of Data Set Ready signal
2 HANGUP After connection lost, waiting to reconnect
3 CONNECTING Dialing initiated, waiting for carrier
4 RINGING Reflects state of Ring Indicator signal
5 CONNECTED Reflects state of Data Carrier Detect signal
11/98 7-1 U3-1050
Westinghouse Proprietary Class 2C
Section 7. Configuration File Examples
7-1. Section Overview
This section provides example fragments of configuration files.
7-2. Examples
These are some examples demonstrating the configuration of the interface to
accomplish various tasks.
7-2.1. Example 1
An interface is needed to a controller which communicates using the Modbus
protocol. The controller has analog values in registers HR40001 through HR40009
representing two temperatures and a pressure for each of three units. The sixteen bit
Modbus registers are holding data from twelve bit I/O and so range from 0 to 4095
counts.

表6-1。调制解调器状态字（ModemStatusReg）
位状态描述
0表示数据集就绪信号的状态
2连接丢失后挂断，等待重新连接
3已启动连接拨号，正在等待运营商
4振铃反映振铃指示灯信号的状态
5.连接反映数据载波检测信号的状态
1998年11月7-1 U3-1050
西屋专有2C级
第七节。配置文件示例
7-1. 章节概述
本节提供配置文件的示例片段。
7-2. 例子
以下是一些示例，演示了
完成各种任务。
7-2.1. 例1
控制器需要一个使用Modbus进行通信的接口
协议控制器在寄存器HR40001到HR40009中有模拟值
代表三个单元中每个单元的两个温度和一个压力。十六位
Modbus寄存器保存来自12位I/O的数据，因此范围从0到4095
计数。
