For the temperatures, 0 represents -50 degrees Fahrenheit, 4095 represents
250 degrees. For the pressures, 0 represents 0 psi and 4095 represents 200 psi.
HR40010 bit 0 represents the running state for Unit 1, bits 1 and 2 represent the
same for Units 2 and 3. Bits 3, 4, and 5 represent an alarm condition for each of the
three units.
In addition, coils C10001, C10002, and C10003 are used to start/stop Units 1, 2, and
3 respectively.
This interface will operate at 9600 baud with no parity and eight data bits. The
controller is at Modbus unit address 5.
7-2. Examples
U3-1050 7-2 11/98
Westinghouse Proprietary Class 2C
In group one of the example, all the data to be read from the controller is specified.

对于温度，0代表-50华氏度，4095代表
250度。对于压力，0代表0 psi，4095代表200 psi。
HR40010位0表示一单元的运行状态，位1和2表示
二单元和三单元也一样。3位、4位和5位表示每个报警的报警条件
三个单位。
此外，线圈C10001、C10002和C10003用于启动/停止1号、2号和3号机组
分别为3。
该接口将在9600波特下工作，无奇偶校验和八个数据位。这个
控制器位于Modbus单元地址5处。
7-2. 例子
U3-1050 7-2 11/98
西屋专有2C级
在示例的一组中，指定了要从控制器读取的所有数据。
