these three attributes:
• DXR=hangup
• CD=detect
• XTS=disabled
This allows the serial driver to report and affect the handshake lines.
U3-1050 6-2 11/98
Westinghouse Proprietary Class 2C
The attribute ModemStatusReg is used to define an LC module register location in
which modem status is to be placed. The status values placed in the register are
listed in Table 6-1.
The attribute ModemTimerReg is used to define an LC module register location in
which the modem timer value is to be placed. The value placed in the modem timer
register is of significance only when bits MSW_HANGUP or
MSW_CONNECTING are true.
When MSW_HANGUP is true, the value represents the amount of time the DTR
line has been held off.
When MSW_CONNECTING is true, the value represents the amount of time since
DTR was raised while waiting for a successful connection.
The attribute ModemHangupTime is used to tell the interface how long to hold
DTR false when the absence of Carrier Detect has been noticed.
ModemHangupTime defaults to five seconds and its purpose is to allow the modems
to settle.
The attribute ModemWaitConnect is used to tell the interface how long to wait for
the local modem to connect to the remote modem before giving up. This attribute
defaults to sixty seconds.

这三个属性：
•DXR=挂断
•CD=检测
•XTS=禁用
这允许串行驱动程序报告并影响握手线路。
U3-1050 6-2 11/98
西屋专有2C级
属性ModemStatusReg用于定义中的LC模块寄存器位置
要放置的调制解调器状态。寄存器中的状态值为
如表6-1所示。
属性ModemTimerReg用于定义中的LC模块寄存器位置
要放置的调制解调器定时器值。放置在调制解调器定时器中的值
寄存器只有在位MSW_挂起或
MSW_连接是真的。
当MSW_HANGUP为true时，该值表示DTR的运行时间
电话线被耽搁了。
当MSW_CONNECTING为true时，该值表示自
在等待成功连接时引发DTR。
属性ModemAnguptime用于告诉接口要保留多长时间
当发现没有载波检测时，DTR为假。
ModemAnguptime默认为5秒，其目的是允许调制解调器
解决。
属性ModemWaitConnect用于告诉接口等待多长时间
本地调制解调器在放弃之前连接到远程调制解调器。这个属性
默认为60秒。
