Modbus Command RCS, RIS, RHR, RIR, FSC,
PSR, RES, FMC, PMR,
FSC_E, PSR_E, FMC_E,
PMR_E, DELAY, SET
Mnemonic keyword which indicates Modbus
function code. (See Table 3-5 for details)
Slave Address 1 to 255 Modbus slave address.
Modbus Address 0 to 9999 Modbus address in protocol form (that is,
40001 = 0, 30001 = 0, 10001 = 0, 1 = 0)
(See Table 3-6 for details)
Modbus Data Type int16, short; uint16, word;
int32, long; uint32, ulong;
int32rev; uint32rev;
bdc4; bcd8; float; floatrev
Specifies interpretation of the Modbus
register values. (See Table 3-7 and Table 3-8
for details)
3-2. Create the Configuration File
11/98 3-11 U3-1050
Westinghouse Proprietary Class 2C
Pseudo-Point Names as LC Addresses
To provide compatibility between the configuration file of the LC/Modbus link and
that of links on other WDPF platforms, the point group list field which normally

Modbus命令RCS、RIS、RHR、RIR、FSC、，
PSR、RES、FMC、PMR、，
FSC_E、PSR_E、FMC_E、，
PMR_E，延迟，设置
表示Modbus的助记符关键字
函数代码。（详见表3-5）
从机地址1到255 Modbus从机地址。
协议形式的Modbus地址0至9999 Modbus地址（即，
40001 = 0, 30001 = 0, 10001 = 0, 1 = 0)
（详见表3-6）
Modbus数据类型int16，短；uint16，单词；
int32，长；uint32，ulong；
int32rev；uint32rev；
bdc4；bcd8；浮动浮雕
指定Modbus的解释
注册值。（见表3-7和表3-8）
（详情请参阅）
3-2. 创建配置文件
1998年11月3-11 U3-1050
西屋专有2C级
伪点名称作为LC地址
提供LC/Modbus链路的配置文件与
其他WDPF平台上的链接，通常
