Create the Configuration File
U3-1050 3-10 11/98
Westinghouse Proprietary Class 2C
3-2.4. /GROUP Point List of Configuration File
Following the /GROUP attribute list in the Group section of a configuration file is
the list of LC address to Modbus address correspondences. Each line of this list
follows a fixed format with position dependent comma separated fields. The first
line illustrated below (in bold) is required, the following lines are optional:
<Link Addr/Point ID>,<Modbus Command>,<Slave Addr>,<Modbus Addr>,
<Modbus Data Type>,<Conversion Type>,<Conversion Factor 1>,
<Conversion Factor 2>,<Conversion Factor 3>,<Conversion Factor 4>,
<Conversion Factor 5>,<Conversion Factor 6>
An example line following this format might look like this:
 D0000, FMC, 1, 1248
The fields comprising the point list are described in Table 3-3.
Table 3-3. /GROUP Point List Fields
Field Range/Value Description
Link Address/
Point ID
D0000 to D2047,
I0000 to I2047,
F0000 to F2046,
S0000 to S2045
The LC memory address.

创建配置文件
U3-1050 3-10 11/98
西屋专有2C级
3-2.4. /配置文件的组点列表
配置文件的组部分中的/GROUP属性列表后面是
LC地址与Modbus地址对应的列表。列表中的每一行
采用固定格式，带有位置相关的逗号分隔字段。一个
下图中的行（粗体）是必需的，以下行是可选的：
<Link Addr/Point ID>，<Modbus Command>，<Slave Addr>，<Modbus Addr>，
<Modbus数据类型>，<Conversion Type>，<Conversion Factor 1>，
<Conversion Factor 2>，<Conversion Factor 3>，<Conversion Factor 4>，
<Conversion Factor 5>，<Conversion Factor 6>
遵循此格式的示例行可能如下所示：
D0000，FMC，11248
构成点列表的字段如表3-3所述。
表3-3/分组点列表字段
字段范围/值说明
链接地址/
点ID
D0000至D2047，
I0000到I2047，
F0000至F2046，
S0000至S2045
LC内存地址。
