0100 through 0109 to Modbus holding registers HR40001 through HR40009.
Next, a message using Modbus function Read Input Registers will be sent to
Modbus slave 1 to read bits 00 through 15 of Modbus input register IR30770 and
bits 00 through of IR30772 into LC memory locations 0200 through 0231.
Notice that the floating point values take up two locations in the LC and two
Modbus registers.
When processing group seven, the integer values at LC memory locations 0300
through 0315 will be checked once per second, and if any have changed, the values
will be sent to Modbus slave 15 holding registers HR40001 through HR40016 using
Modbus function Preset Multiple Registers.
This group exemplifies operation when using _E to indicate writing by exception.
It also shows that the group number has no significance to order of operation and
can be used for book-keeping or documentary purposes.
3-2. Create the Configuration File
U3-1050 3-6 11/98
Westinghouse Proprietary Class 2C
3-2.2. /FILE Section of Configuration File
The /FILE section of the configuration file specifies attributes of the link as a whole,
such as port settings. An example of the /FILE section of a configuration file is

0100至0109至Modbus保持寄存器HR40001至HR40009。
接下来，将使用Modbus功能读取输入寄存器向
Modbus从机1读取Modbus输入寄存器IR30770的位00至15，以及
IR30772的位00至，进入LC存储器单元0200至0231。
请注意，浮点值占据LC中的两个位置和两个位置
Modbus寄存器。
处理第七组时，LC内存位置0300处的整数值
到0315将每秒检查一次，如果有变化，则检查值
将被发送至Modbus从机15，保存寄存器HR40001至HR40016，使用
Modbus功能预设多个寄存器。
本组举例说明了使用_E表示异常写入时的操作。
这也表明，组号对操作顺序和顺序没有意义
可用于记账或记录目的。
3-2. 创建配置文件
U3-1050 3-6 11/98
西屋专有2C级
3-2.2. /配置文件的文件部分
配置文件的/FILE部分指定链接作为一个整体的属性，
例如端口设置。配置文件的/FILE部分的一个示例是
