3500 Data Acquisition
Software, and 3500 Display
Software
BN TDI Protocol
Communication with
System 1 Condition
Monitoring and Diagnostic
Software
Front Panel
This disk enables the number of channels of
dynamic data (i.e., the ability to collect
waveforms) that the TDI will support. There are
two levels of dynamic data. Steady-State
points are channels that collect waveform data
due either to a software command or to an
alarm event, and therefore support current
values, scheduled waveform capture, and
alarm data capture. Transient points provide all
the function of a Steady-State point with the
additional capability of waveform collection
due to parameter variations such as machine
speed.
3500/09-AAA-BBB
A: Steady-State Points
000 to 672 Steady-State Points
B: Transient Points
002 to 672 Transient Points
The sum of the two fields must be equal
to or less than 672. One disk can support
multiple TDIs.
Ethernet Cables
Standard 10 Base-T/100 Base-TX Shielded
Category 5 Cable with RJ-45 connecto

3500数据采集
软件和3500显示屏
软件
BN-TDI协议
沟通
系统1条件
监测和诊断
软件
前面板
此磁盘可启用
动态数据（即收集数据的能力）
TDI将支持的波形）。有
两级动态数据。稳态
点是收集波形数据的通道
由于软件命令或
报警事件，因此支持当前
值、计划波形捕获和
报警数据捕获。瞬变点提供所有
稳态点的函数
额外的波形采集功能
由于机器等参数变化
速度
3500/09-AAA-BBB
答：稳态点
000到672个稳态点
B:瞬变点
002至672个瞬态点
两个字段之和必须相等
小于等于672。一个磁盘可以支持
多个TDI。
以太网电缆
标准10 Base-T/100 Base-TX屏蔽
带有RJ-45连接器的5类电缆
