l Supports multiple events per revolution speed inputs up to 20 kHz Startup/Coastdown Data l Data collected at selected increments of speed and time l Increasing and decreasing speed intervals are independently programmable l Initiation of transient data collection based on detecting the machine speed within one of two programmable windows l The number of transient events that can be collected is only limited by the available memory in the module Alarm Data Collection l Pre- and post-alarm data l Static values collected at one second intervals for 10 minutes before the event and 1 minute after the event l Static values collected at 100 ms intervals for 20 seconds before the event and 10 seconds after the event l 2.5 minutes of waveform data collected at 10-second intervals before the alarm and 1 minute of waveform data collected at 10-second intervals after the alarm Static Values Data l TDI will collect the static values including the values measured by the monitors. l TDI provides four nX static values for each point. Amplitude and phase are returned for each of the values.l支持每转多个事件
速度输入高达20 kHz
启动/滑行数据
l以选定的增量收集的数据
速度和时间
l增加和减少速度
间隔是独立的
可编程
l启动瞬态数据采集
基于检测机器速度
在两个可编程
窗户
l可能发生的瞬态事件的数量
要收集的信息仅限于
模块中的可用内存
报警数据采集
l报警前和报警后数据
l每秒采集的静态值
活动前10分钟的休息时间
活动结束后1分钟
l每隔100毫秒采集一次静态值
比赛前20秒，10秒
赛后几秒钟
l收集2.5分钟的波形数据
警报前每隔10秒
收集1分钟的波形数据
警报后每隔10秒
静态值数据
l TDI将收集静态值，包括
监视器测量的值。
l TDI为每个传感器提供四个nX静态值
指向返回振幅和相位
对于每个值。
