3500/22M瞬态数据接口（TDI）是

3500监控系统和兼容系统之间

软件（系统1状态监测和诊断

软件和3500系统配置软件）。TDI

结合3500/20机架接口模块的功能

（RIM）具有通信的数据收集能力

处理器，如TDXnet。

TDI位于与电源相邻的插槽中

3500机架。它与M系列监测器（3500/40M，

3500/42M等），以持续收集稳态和

瞬态动态（波形）数据并传递该数据

通过以太网连接到主机软件。参考

更多信息，请参阅本文档末尾的兼容性部分

信息

静态数据捕获能力是TDI的标准配置。

但是，使用可选通道启用磁盘将允许

用于捕捉动态和高分辨率瞬态的TDI

数据也是如此。TDI包含通信

3500机架内的处理器功能。

虽然TDI提供了某些通用功能

整个机架，它不是关键监控路径的一部分

对整个系统的正常运行没有影响

用于自动机械保护的监控系统。每一个

3500机架需要一个TDI或RIM，它总是占用插槽1

（电源旁边）。


The 3500/22M Transient Data Interface (TDI) is the interface
between the 3500 monitoring system and compatible
software (System 1 Condition Monitoring and Diagnostic
software and 3500 System Configuration software). The TDI
combines the function of a 3500/20 Rack Interface Module
(RIM) with the data collection capability of a communication
processor such as TDXnet.
The TDI resides in the slot adjacent to the power supplies of a
3500 rack. It interfaces with M series monitors (3500/40M,
3500/42M, etc.) to continuously collect steady state and
transient dynamic (waveform) data and pass this data
through an Ethernet link to the host software. Refer to the
Compatibility section at the end of this document for more
information.
Static data capture capability is standard with the TDI.
However, using an optional Channel Enabling Disk will allow
the TDI to capture dynamic and high-resolution transient
data as well. The TDI incorporates the communication
processor function within the 3500 rack.
Although the TDI provides certain functions common to the
entire rack, it is not part of the critical monitoring path and
has no effect on the proper, normal operation of the overall
monitor system for automatic machinery protection. Every
3500 rack requires one TDI or RIM, which always occupies Slot 1
(next to the power supplies).
