环境规范
环境的
温度
-40至60摄氏度
冲击10 G½-正弦波11 ms
从5 Hz到1 mm的峰间振动
至16赫兹，0.5克从16赫兹至
150赫兹
空运的
污染物
ISA-S71。04-1985空降
G3类污染物
相对湿度5%至95%不冷凝
注：序列号和位置见产品标签
以及生产日期。
警告：本产品有特定的使用说明
危险区域的安装、拆除和操作。
参考文件12P2046“DeltaV™ 可伸缩
工艺系统2区安装说明”其他
安装说明可在“安装”中找到
你的DeltaV自动化系统手册。
连接到DeltaV的通讯网络
控制器不得连接到
在正常情况下生成或包含
电势超过60伏交流电或75伏直流电。
移除和插入
此单元不能随系统一起卸下或插入
电源通电。


Environmental Specifications Ambient Temperature -40 to 60° C Shock 10 G ½-sinewave for 11 ms Vibration 1 mm peak-to-peak from 5 Hz to 16 Hz, 0.5 g from 16 Hz to 150 Hz Airborne Contaminants ISA-S71.04 –1985 Airborne Contaminants Class G3 Relative Humidity 5% to 95% non-condensing Note: See product label for serial number and location and date of manufacture. Warning: This product has specific instructions for installation, removal and operation in hazardous areas. Refer to document 12P2046 "DeltaV ™ Scalable Process System Zone 2 Installation Instructions". Other installation instructions are available in the "Installing Your DeltaV Automation System" manual. The communications network connected to the DeltaV Controller must not be connected to a source that generates or contains under normal conditions a potential in excess of 60 VAC or 75 VDC. Removal and Insertion This unit cannot be removed or inserted with system power energized.
