提供给该设备的现场电源
终端或现场总线电源通过
在拆卸或更换托架之前，必须先拆下托架
连接设备。
必须在所有设备上完成I/O回路评估
能量有限的节点。
系统运行时，可以卸下或插入该装置
电源在以下条件下通电：
（注：每次只能拆下一个单元）
系统电源已通电。）
•与KJ1501X1-BC1双系统一起使用时
在24 VDC或以下电压下运行的DC/DC电源
12 VDC输入电源。主电路接线
输入功率的电感必须小于23
或者是有开路的认证电源
电压，Ui为12.6 VDC，Lo小于
23 uH（包括导线电感）。
旋转键控系统确保兼容性
在I/O卡和接线板之间
安装完成。接线板必须
为要使用的I/O卡设置密钥
被利用。
接线盒保险丝不能与其他部件一起拆下
为无火花电路通电的现场电源。


Field power supplied to this device, either at the field terminal or as bussed field power through the carrier, must be removed before removing or connecting the device. An I/O loop assessment must be complete on all energy limited nodes. This unit may be removed or inserted while system power is energized under the following conditions: (Note Only one unit at a time may be removed with system power energized.) • When used with KJ1501X1-BC1 System Dual DC/DC Power Supply operating on 24 VDC or 12 VDC input power. The primary circuit wiring inductance for input power must be less than 23 uH, or a certified supply with an open circuit voltage, Ui of 12.6 VDC and an Lo of less than 23 uH (including wire inductance). A rotary keying system ensures compatibility between I/O cards and terminal blocks after installation is complete. The terminal block must have the keys set for the I/O card with which it is to be used. A terminal block fuse may NOT be removed with field power energized for non-sparking circuits.
