特征
•额定容量为500至20000磅
•不锈钢焊接密封结构
•整体式装载支架
•与TCM张力安装硬件兼容
•设计用于单个或多个称重传感器应用
•通过NTEP IIIL级贸易认证：10000d和
III:5000d
•传感器™ 按IP68标准密封
•批准用于I、II、III类的工厂互助系统；
和二分部；A组至G组。
此外，非煽动性评级（无障碍！）
•可选
❍ 安装和装载附件硬件可用
应用
•恶劣环境：食品和饮料加工
化工和塑料加工
制药和生物医学
•料仓、料斗和皮带输送机秤
•水平和库存监测
•张力和压缩测量
描述
60063型是不锈钢S型称重传感器。它的
焊接密封结合高精度，使之
称重传感器非常适合各种应用
过程称重和测力。
批准包括NTEP III 5000d单体和NTEP
IIIL10000d倍数。也可提供已批准的版本
对于危险区域——FM I、II、III1部分。

　
FEATURES
• Rated capacities of 500 to 20,000 pounds
• Stainless steel, welded seal construction
• Integral loading brackets
• Compatible with TCM tension mounting hardware
• Designed for single or multiple load cell applications
• Trade certified for NTEP Class IIIL: 10000d and
III: 5000d
• Sensorgage™ sealed to IP68 standards
• Factory Mutual System Approved for Classes I, II, III;
Divisions 1 and 2; Groups A through G.
Also, non-incendive ratings (No barriers!)
• Optional
❍ Mounting and loading accessory hardware available
APPLICATIONS
• Hostile environments: Food and beverage processing
Chemical and plastics processing
Pharmaceutical and biomedical
• Bin, hopper and belt conveyor scales
• Level and inventory monitoring
• Tension and compression measurements
DESCRIPTION
Model 60063 is a stainless steel S-Type load cell. Its
welded sealing combined with high accuracy, make this
load cell ideally suited for a wide range of applications of
process weighing and force measurement.
Approvals included NTEP III 5000d single and NTEP
IIIL10000d multiple. Also available are versions approved
for hazardous areas - FM I, II, III Division 1.
